CONTINUOUS MINER
CONTINUOUS MINER
Gainwell continuous miners offer superior performance and productivity combined with high availability and low maintenance; resulting in higher production, lower maintenance cost per tonne and, as a result, lower total cost of ownership.
Wide range of sizes that allows working in seams in any height
Higher cutting power for more productivity
Fastest loading capacity in
industry
Engineering features that contribute to long, reliable service between overhauls. This means greater productivity and higher tonnage between rebuilds.
Higher cutter motor power and a heavier chassis than competitive models, offers superior performance in hard-cutting applications.
Infinitely variable tram control allows precise control of steering, speed and traction with independent control of the two sides.
75 mm steel plate for the main frame – 50% thicker than competitors. The heavier, more rigid frame allows a better cutting rate.
Machine Control Unit designed to operate the entire Gainwell continuous miner. As traction motors are controlled by a microprocessor-based system, the design minimizes the connection points that are the major cause of downtime.
| Mining range (recommended) | 1270 - 2540 mm | 50 - 100 in |
| Weight (total) | 63.5 tonnes | 140,000 lbs |
| Total Power | 680 kW | 910 hp (one-hour rating w/o scrubber) |
| Mining range (recommended) | 1524 – 3404 mm | 60 -134 in |
| Weight (total) | 61.3 tonnes | 135,000 lbs |
| Total Power | 686 kW | 920 hp (one hour rating) |
| Mining range (recommended) | 1067-2946 mm | 42-116 in |
| Weight (total) | 61.2 tonnes | 135,000 lbs |
| Total Power | 701 kW | 940 hp (one-hour rating w/o scrubber) |
| Mining range (recommended) | 1524 – 3404 mm | 60 -134 in |
| Weight (total) | 61.3 tonnes | 135,000 lbs |
| Total Power | 686 kW | 920 hp (one hour rating) |
| Mining range (recommended) | 1676-3632 mm | 66-143 in |
| Weight (total) | 68 tonnes | 150,000 lbs |
| Total Power | 694 kW | 930 hp (one-hour Rating without scrubber) |
| Mining range (recommended) | 1676 - 3810 mm | 66 - 150 in |
| Weight (total) | 70.3 tonnes | 155,000 lbs |
| Total Power | 675 kW | 905 hp (one-hour rating) |
| Mining range (recommended) | 2210 - 4318 mm | 87-170 in |
| Weight (total) | 74.8 tonnes | 165,000 lbs |
| Total Power | 727 kW | 975 hp (one-hour Rating without scrubber) |
| Mining range (recommended) | 1651 – 3480 mm | 65 - 137 in |
| Weight (total) | 85.7 tonnes | 189,000 lbs |
| Total Power | 727 kW | 975 hp (one-hour rating) |
| Mining range (recommended) | 2800 - 3900 mm | 110.2 in - 153.5 in |
| Weight (total) | 92 tonnes | 202,800 lbs |
| Total Power | 674 kW | 904 hp(one-hour rating) |
